478
Administration and Servicing
Assigning an IP Address to Each Device in your System
By default, all network adapters are set to auto-negotiate. The connection speed and
duplex mode will be set automatically based on the corresponding port settings on the
associated switch. The current speed and link mode are displayed next to Detected link
mode, for every network adapter.
8 Should your network configuration require specific speed and duplex mode settings,
select the appropriate value from the Configured link mode list.
9 Click Save.
The new settings are saved locally.
10 Click OK.
The Apply settings button becomes available.
11 Click Apply settings.
The Kaleido-X system must be restarted for changes to the network configuration to
take effect. A message appears prompting you to reboot the system immediately.
12 Click OK.
Remember to change your client PC’s IP address to one that matches the new subnet
(see
Changing the Client PC’s IP Address on page 480). You will also need to edit the
XAdmin URL in your Web browser's address bar, in order to log on to the multiviewer
again.
Note: As required by the IEEE-802.3 standard, section 28D.5, 1000 Mbps
full-duplex communication is only supported via auto-negotiation.
Note: Settings cannot be applied to a multiviewer system while an
upgrade is in progress. If the multiviewer does not reboot after 10 seconds
or so, try clicking Apply settings again after a minute or two, until the
multiviewer reboots.
