To calibrate loudness probe assignments
1 In the main window, click the System tab, and then click Description/Calibrations on
the second-level tab bar.
A hierarchical list representing the current system appears.
2 In the list, expand the multiviewer whose inputs you wish to calibrate.
3 Expand the appropriate input, and then click Loudness probe assignment.
4 In the Properties pane, assign an audio program to one of the 16 available probes.
The default is Program 1 for all video inputs.
Calibrating Dolby Dialog Loudness Measurement
Note:
If you choose to measure the second program for a specific video
input, you will not be able to measure audio programs on all inputs.
Note:
This section applies to Kaleido-X with first-generation input cards
(KXI-16SV rev. 599 and earlier, KXI-16HS, and KXI-16HSV), only.
If you have a Kaleido-X16, and to Kaleido-X multiviewers with second-
generation input cards (KXI-16SV rev. 600 and later, KXI-16HS3, and KXI-
16HSV3), see
