Operating information
Capturing data
102 Operating Instructions
Data
To open the Data screen:
Click the «Data» button.
The Data screen is displayed in the content area. A message verifying the action is
displayed in the message area.
Data capture Data can be captured from MSEsetup or with a HEIDENHAIN foot switch (ID
681041-03).
To capture data:
Click the «OK» button in the Data screen.
or
Press foot switch button 1 or 2. Refer to the documentation provided with the foot
switch for further information.
Data values are captured in the data screen and exported to the output file based
on Data capture settings.
Delete last record Deleting the last data record is available by default when exporting to a Microsoft Excel
file. If the Delete button is not visible, verify that the Output File Type is set to .xlsx in
the Configuration screen. Refer to "Data capture", page 51.
To delete the last data record:
Click the «Delete» button.
The last captured data record is deleted from the list.
Delete all records To delete all data records:
Click the «Delete all» button.
A dialog window appears to confirm the request.
Click the «OK» button.
All captured data records are deleted from the list.
Reset min/max To reset Min and Max values:
Click the «Reset» button.
Minimum and maximum data capture values are reset to zero.
