Software setup
MSEsetup overview
Operating Instructions 47
File dialog window controls
A
Directory drop down
list
Displays the current folder location. The list contains the
last 10 folders used. The most recently selected folder is
placed at the end of the list.
B Parent directory button Navigates from the current folder to its parent folder.
C System directory
button
Navigates to the system folder.
D User directory button Navigates to the user folder.
E
Current directory
contents
Double clicking on a folder name will navigate to the folder.
Clicking on a file name will select the file.
F
File name field
Field used to enter a file name.
G
File type field
Displays the required file type.
H Confirmation buttons Used to confirm or cancel an action.
