Commissioning and preparing to measure
Network configuration
68 Operating Instructions
Limited broadcast To send a limited broadcast:
Select the 255.255.255.255 netmask from the Broadcast netmask drop-down list.
Click the «Broadcast» button.
A dialog box displays the number of modules found.
Click the «OK» button to overwrite the configurable module settings from a backup
file or click the «Cancel» button to proceed without overwriting the settings.
A message verifying that broadcasting is finished is displayed in the Connect
screen message area.
Directed broadcast To send a directed broadcast:
Select a directed broadcast netmask option from the Broadcast netmask drop-
down list.
Direct broadcast netmask options:
255.255.255.0
255.255.0.0
255.0.0.0
The Workstation IP is masked with the value in the drop-down list to localize the
broadcast to a specific subnetwork.
Click the «Broadcast» button.
A dialog box displays the number of modules found.
Click the «OK» button to overwrite the configurable module settings from a backup
file or click the «Cancel» button to proceed without overwriting the settings.
A message verifying that broadcasting is finished is displayed in the Connect
screen message area.
