Troubleshooting
Encoder warnings and errors
148 Operating Instructions
12.6 Module configuration file errors
Error Cause Corrective action
Invalid file
The requested configuration file is
invalid.
DOM root element is NULL The root element of the
configuration file is not valid.
Invalid tagname for ModuleConfig The ModuleConfig tag name was
not found in the configuration file.
Invalid tagname for the module The Module tag name was not
found in the configuration file.
Invalid tagname for the channel
The Channel tag name was not
found in the configuration file.
Invalid module list
The tag name for the desired
module element could not be found.
Invalid channel list
The tag name for the desired
channel element could not be found.
Tag name not found
The tag name for the desired
element could not be found.
Load a good Module Configuration
file. Refer to "File options",
page 57.
Restart MSEsetup.
or
Delete the Module Configuration
file. Refer to File locations, page 34
for configuration file locations.
Perform a broadcast.
Failed to overwrite all of the
selected modules configurable
settings
The file being merged with the
ModuleConfig.xml file is invalid. Choose a different file to merge
with the ModuleConfig.xml file.
12.7 Device warnings and errors
Warning Cause Corrective action
Calibration needs to be performed
An analog or LVDT device needs to
be calibrated. Recalculate the resolution of the
analog or LVDT device.
Mastering must be redone since the
device settings changed
A device's setting has been changed
that has invalidated the master
position. Clear the warning and re-master
the device from the master screen.
12.8 Encoder warnings and errors
Encoder warnings and errors are reported in the "Error screen", page 138 and the "Diagnostics", page 126. Refer to the
documentation provided with the encoder for troubleshooting information.
