Commissioning and preparing to measure
Network configuration
66 Operating Instructions
Set Asynchronous Port The Asynchronous Port number is used to receive asynchronous messages from
MSE 1000 modules on the workstation IP address. This option only needs to be
modified if there is another application using the same IP address and asynchronous
port number.
The asynchronous port number must be between 1024 - 49151 and cannot be the
same as the port. See "Set Port", page 65 for information on the port. The default
asynchronous port number is 27300.
To set the Asynchronous Port:
Enter a port value into the Async. Port field.
Click the «Async. Port» button.
A dialog window appears asking if the port should be changed.
Click the «OK» button.
A dialog window appears stating that MSEsetup will restart. A message verifying
the action is displayed in the message area.
Click the «OK» button.
