Installation and commissioning examples
Example using manual IP address assignment
Operating Instructions 117
10.2.4 Install the software
Install MSEsetup Download and install the MSEsetup application software. Refer to "Installing
MSEsetup", page 34.
10.2.5 Open the software
Open MSEsetup Double-click the MSEsetup desktop icon to open MSEsetup. Refer to Opening
MSEsetup"", page 48.
10.2.6 Configure the workstation NIC
Configure the
workstation IP Configure the workstation NIC IP address to 172.31.46.3 in the workstation PC
networking settings. Refer to the documentation provided with the PC or NIC for
configuration instructions.
Configure the
workstation Subnet
mask Configure the workstation Subnet mask to 255.255.255.0 in the workstation PC
networking settings. Refer to the documentation provided with the PC or NIC for
configuration instructions.
10.2.7 Power-up the modules
Power-up Press the On (supply) side of the power switch to power-up the system. Refer to
"Initial power-up", page 33.
10.2.8 Configure the workstation IP, power supply, and base module
network communication settings
The power LED's on each module light solid green. Network LED's initially flash green
five times per second when waiting for DHCP to assign an IP address. After a 45
second timeout the modules will stop waiting for DHCP to assign an IP address and
the Network LED's on each module will flash green twice per second.
Wait for the Network LED to flash green twice per second on all modules.
