Install the end covers
Install end covers
Install the left end cover on the left side of the power supply module. Refer to
"Installing end covers", page 21.
Install the right end cover on the right side of the 4-channel EnDat module. Refer to
"Installing end covers", page 21.
10.2.12 Connect the encoders
Connect the 1 V
PP
encoder
Connect the 1 V
PP
encoder to the MSE 1184 (ID 747500-01) X1 connector
17
. Refer
to "Connecting a 1 VPP encoder", page 29.
Connect the EnDat
encoder
Connect the EnDat encoder to the MSE 1314 (ID 747503-01) X11 connector
16
.
Refer to "Connecting an EnDat encoder", page 28.
10.2.13 Secure the cables
Install cable mounting
hardware
Install the cable mounting hardware provided with each module. Refer to "Installing
cable mounting hardware", page 21.
Secure cables
Secure all cables to the cable mounting hardware using the supplied cable tie's.
10.2.14 Power-up the modules
Power-up
Press the On (supply) side of the power switch to power-up the system. Refer to
"Initial power-up", page 33.
