Software setup
MSEsetup configuration
Operating Instructions 61
7.4.12 Update firmware
The Update firmware screen provides options for updating the firmware and bootloader
installed on MSE 1000 modules. Update firmware is available only when supervisor
mode is enabled.
Update firmware
NOTICE
Do not update the firmware when Use DHCP addressing is enabled. Refer to DHCP
addressing"", page 70 for additional information.
NOTICE
Programming the firmware with a version newer than v1.0.2 requires the bootloader
be at least v1.0.2.
The bootloader and firmware cannot be programmed to a version older than v1.0.3
once programmed to v1.0.3 or newer.
To update the module firmware:
Click the «Open» button.
The file dialog window opens.
Use the File dialog window controls to select a firmware file to load.
Click the Module selection drop-down arrow and select a single module to update
or «All» to update all modules.
Modules will not be programmed if the new version matches the current version
when «All» is selected.
If required, click the «Firmware/Bootloader» button and select Firmware.
Click the «OK» button.
The firmware update begins. Refer to the status indicator for the current status of
the update.
