Installation
Data interface connections
Operating Instructions 27
5.1.3 Connecting a power cord
MSE 1201
(ID 747501-01) To connect the MSE 1201 (ID 747501-01) power cord:
Verify that the power switch is in the off position.
Verify that the power cord is not plugged into the main power supply.
Insert the female end of the power cord into the power connector 4 on the front of
the module.
MSE 1201
(ID 747501-02) To connect the MSE 1201 (ID 747501-02) power cord:
Verify that there is no power at the source.
Wire the power cable to the source.
MSE 1202
(ID 747502-01) To connect the MSE 1202 (ID 747502-01) power cord:
Verify that the power cord is not plugged into the main power supply.
Align the cable connector with the module connector.
Insert the power cord connector into the power connector 13 on the front of the
module.
Hand tighten the M8 connector onto the module.
5.2 Data interface connections
5.2.1 Connecting a foot switch
14
Foot switch
connector
This product can be used with HEIDENHAIN foot switch (ID 681041-03).
To connect a foot switch:
Verify power is removed from all power supply modules in the module chain.
Connect the foot switch cable connector to the foot switch connection 14 on the
module and tighten the cable connector screws until they are snug.
