Software setup
MSEsetup overview
Operating Instructions 39
Confirmation buttons
Button Function
OK: Confirms or starts an action.
Cancel or Delete: Deletes data or cancels an action.
Enable/disable buttons
Button Function
Enabled: Shows that an option is enabled. Clicking the button will toggle the
option to disabled.
Disabled: Shows that an option is disabled. Clicking the button will toggle the
option to enabled.
Setup screen buttons
Button Function
Calibration screen: Opens the calibration screen for calibrating LVDT modules.
Clicking will toggle the button to the Setup screen button.
Setup screen: Returns to the setup screen from the LVDT calibration screen.
Clicking will toggle the button to the Calibration screen button.
LVDT teach resolution screen buttons
Button Function
SetAllMin: Sets the minimum position value for all sensors. Minimum position
values are used when calculating sensor resolution.
SetAllMax: Sets the maximum position value for all sensors. Maximum position
values are used when calculating sensor resolution.
