Installation
24 Operating Instructions
Interfaces
16 Encoder inputs: X11 ... X18 axis for EnDat interface encoders. The number of
axes varies by module.
17 Encoder inputs: X21 ... X28 axis for TTL interface encoders. The number of axes
varies by module.
18 Encoder inputs: X1 ... X8 axis for 1 V
PP
interface encoders. The number of axes
varies by module.
19 9-pin D-sub: X31, X32 for analog input.
20 Transducer inputs: X41 ... X48 axis for LVDT and half-bridge transducers.
21 Terminal block: X102 for I/O.
22 Terminal block: X101 for I/O power.
23 3-pin M8: X102 I1, I2, I3, I4 for switching input.
24 3-pin M8: X102 O1, O2, O3, O4 for relay output.
25 3-pin M8: X101 for I/O power.
26 Plug-in connection for compressed air input.
27 Muffler for pressure relief.
28 Plug-in connection for compressed air output.
