Installation and commissioning examples
Example using manual IP address assignment
118 Operating Instructions
Open the
Configuration screen Click the «Config» button.
Enable Supervisor
mode Click the «Supervisor mode» button.
Enter "95148" into the Password field.
Open the Connect
screen Click the «Connect» button.
Configure the
Workstation IP Select «172.31.46.3» from the Workstation IP drop-down list.
Select «255.255.255.0» from the Netmask drop-down list.
Refer to "Workstation IP", page 65.
Perform a Broadcast Click the «Broadcast» button.
A dialog box appears asking to configure the modules using a backup file.
Click the «Cancel» button.
A dialog box appears asking to configure the modules to use static addressing.
Click the «OK» button.
A dialog box appears verifying the modules have been set to use static addressing
and requesting to cycle power.
Cycle the power Turn the power off, wait 20 seconds then turn the power on.
Wait for the Network LED's to flash twice per second on all modules.
Click the «OK» button in the dialog box.
Click the «Cancel» button when requested to overwrite the settings from a backup
file.
