Installation and commissioning examples
Example using manual IP address assignment
Operating Instructions 121
10.2.15 Configure the EnDat module network communication settings
The power LED's on each module light solid green. Network LED's flash green twice
per second.
Wait for the Network LED's to flash green twice per second on all modules.
Perform a Broadcast Click the «Broadcast» button.
A dialog box appears asking to configure the EnDat module to use static
addressing.
Configure the EnDat
module for static
addressing Click the «OK» button.
A dialog box confirms the EnDat module has been configured to use static
addressing.
Cycle the power Turn the power off, wait 20 seconds then turn the power on.
Wait for the Network LED's to flash twice per second on all modules.
Click the «OK» button in the dialog box.
Click the «OK» button to overwrite the settings.
Configure the EnDat
module IP address Select the EnDat module from the Individual Module IP drop-down list.
Click inside the enabled Set Static text field and enter "6" (172.31.46.6).
Click the «Set Static» button.
MSEsetup sets the static IP address and performs a reconnect to the modules.
10.2.16 Setup the 1 V
PP
channel
Open the Setup
screen From the Connect screen, click the «Back» button twice.
Click the «Setup» button.
Select the 1 V
PP
Channel
Click on «X1 (CH1)» under MSE 1184 in the Tree.
Click the «Channel» tab.
Assign the length
gauge to the 1 V
PP
channel
Click and drag the Length Gauge icon to the green square labeled X1. The green
square appears when the length gauge icon is clicked and dragged.
Click the «OK» button.
Refer to "Channel setup", page 83 for additional channel settings options.
