Troubleshooting
Referencing error
Operating Instructions 149
12.9 Module chain reconnect warning
Warning Cause Corrective action
The module chain needs to be
reconnected
This warning occurs when a module
has been rebooted or added to the
module chain without a reconnect or
broadcast.
Modules send out broadcasts once
every 30 seconds with their network
information until they obtain a
connection from MSEsetup. The
service log will show information
regarding the module that is sending
the broadcast.
Click the «Delete all errors» button
to clear the warning.
A dialog window appears
requesting confirmation to recover
from lost communication.
Click the «OK» button.
MSEsetup performs a reconnect.
A Broadcast must be performed
if a new module has been added
to the chain. For additional
information refer to Broadcast"",
page 67.
12.10 Referencing warning
Warning Cause Corrective action
Referencing has not been
completed
Reference marks on 1 V
PP
encoders
have not been traversed.
Traverse reference marks on 1 V
PP
encoders.
For additional information refer to
"Referencing", page 95.
12.11 Referencing error
Error Cause Corrective action
Referencing failed The referencing mark type, line
count, or signal period may be
incorrect for a 1 V
pp
or TTL encoder.
The interpolation may be incorrect
for a TTL encoder.
Change the referencing mark
type, line count, signal period, or
interpolation to the correct value.
