Commissioning and preparing to measure
Device setup
94 Operating Instructions
To set the measured minimum and maximum values for LVDT sensors:
Click inside the Measured min. text field.
Delete the current value.
Enter the minimum value.
Click inside the Measured max. text field.
Delete the current value.
Enter the maximum value.
Click the «OK» button.
A dialog window appears requesting to hold the sensor at the minimum position.
Hold the sensor at the minimum position and click the «OK» button.
A dialog window appears requesting to hold the sensor at the maximum position.
Hold the sensor at the maximum position and click the «OK» button.
The resolution will be updated with the interpolated value.
The calibration timestamp will be updated with the current date and time.
A message verifying the action is displayed in the message area.
Set recalibration timer The recalibration timer is used with analog devices and LVDT sensors. The recalibration
timer provides a notification in the Error screen when it is time to recalibrate the
resolution of a device or sensor.
To set the recalibration timer:
Click inside the Recal. timer text field.
Delete the current value.
Enter the required recalibration timer value.
Click the «OK» button.
A message verifying the action is displayed in the message area.
