Commissioning and preparing to measure
Module setup
78 Operating Instructions
To view Module setup options:
Click the «Setup» button.
Select a module from the Tree or the Module view.
The Module setup tab for the selected module appears in the Setup screen.
Change Module label The Module label is a unique name that can be assigned to a module to help identify it
from other modules in the module chain. The module model number is assigned as the
default label. A maximum of 13 characters may used for the label.
To change the Module label:
Click inside the Module label text field.
Delete the current label.
Enter a unique name for the module.
Click the «OK» button.
A message verifying the action is displayed in the message area.
Activate/deactivate
module A module can be deactivated and left in the module chain and later reactivated. This is
useful if data is not required for a specific task, but is needed for others at a later time.
When a module is deactivated it is no longer polled for updates. Deactivated modules
are removed from the Data and Mastering screens and their diagnostic data is not
available. Module View will show the inactive module in a lighter tint.
To change the active status of a module:
Click «Active» toggle button to change the active status.
Click the «OK» button.
