Software setup
MSEsetup configuration
Operating Instructions 55
7.4.8 Diagnostics mode
Diagnostics mode options are used to set the diagnostics mode running inside MSE
1000 modules.
Disabling Diagnostics mode will speed up data capture when maximum throughput is
desired.
Full diagnostics mode is enabled for a module when the Diagnostics screen is open
and returned to the selected setting when the Diagnostics screen is exited.
Available diagnostics modes:
Full
Status
Minimal
Off
Select diagnostics
mode To select a diagnostics mode:
Click the «Diagnostics mode» button.
Diagnostics mode options are displayed at the top of the screen.
Click the «Diagnostics mode» drop down arrow and select a diagnostics mode.
The updated setting is displayed in the Diagnostics mode drop down box. A
message verifying the action is displayed in the message area.
