8-12
Fax Settings > Default fax settings
TX/RX Restriction
[System Menu/Counter] key > [FAX] > [TX/RX Restriction]
This function allows you to send or receive originals only when communication requirements are met.
Transmission Restriction (page 8-15)
FAX
Rings(FAX/TEL)
If the reception method is FAX/TEL Auto Switch Reception, the number of
rings until the machine answers a call can be changed as needed.
NOTE
This setting does not appear in some regions.
RX Setting
Select the reception mode.
Value:
Auto (Normal), Auto (FAX/TEL), Auto (Answering Machine), Manual,
Auto (DRD)
If Auto (DRD) is selected, select the DRD Pattern.
Value
: Pattern 1 (Normal Ring), Pattern 2 (Double Ring),
Pattern 3 (Short-Short-Long), Pattern 4 (Short-Long-Short)
DRD reception mode is available for some countries.
FAX Reception (page 4-2)
Manual Reception (page 4-4)
DRD Reception (Available for some countries.) (page 5-43)
Remote SW Dial
To start fax reception by operation from the connected telephone set, use the
following operation.
Value
: 00 - 99
Remote Switch Function (page 5-47)
Reception Port
*1
You can make one of the 2 phone lines a receive-only line.
Value
: Off, Port 1, Port 2
Reception Port Selection (page 9-XX)
ECM RX (Port1)
Set whether ECM RX is performed.
ECM is a communication mode specified by the ITU-T (International
Telecommunication Union) that retransmits data when an error occurs. Fax
machines that have ECM mode check for errors as they communicate,
preventing distortion of the image due to noise on the line and other
conditions.
Value
: On, Off
NOTE
When there is a large amount of noise on the line, communication may take slightly
longer than when [Off] is selected.
ECM RX (Port2)
*1
RX Start Speed (Port1)
Change the RX Start Speed.
When communication conditions are bad, the fax may not be received
correctly. In that case, set a lower RX Start Speed.
Value
: 9600bps, 14400bps, 33600bps
NOTE
Normally this should be used with the default setting.
RX Start Speed (Port2)
*1
Encrypted Reception
Turns on reception by encrypted communication.
Value
: Off, On
If turned on, select the encryption key.
*1 This function is displayed when 2 optional FAX Kits (Dual FAX option) are installed.
Item
Description
