1.3 Package Contents
The following components are included with your PLX8X-MNET-61850 gateway,
and are all required for installation and configuration.
Important: Before beginning the installation, verify that all of the following items
are present.
Qty. Part Name Part Number Part Description
1 Modbus TCP/IP to
IEC 61850
gateway PLX8X-MNET-61850 ProSoft communication gateway
1 Ethernet Cable RL-CBL025 5-foot straight-through Ethernet cable (gray)
1 Screwdriver HRD250 Small, flat-bladed screwdriver
1 ProSoft Solutions
DVD DVD-001 Contains utilities and documentation for the
PLX8X-MNET-61850 gateway.
1 1 GB Industrial SD
Card SDCard-1GB Industrial SD card for stored gateway
configuration
1 Power Connector J180 3-wire dc power connector
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
