INT16U
Unsigned integer, 0 to 65 535
IEC 61850-7-3,
IEC 61850-7-2
INT24
-8 388 608 to 8 388 607 (for TimeStamp type)
IEC 61850-7-3,
IEC 61850-7-2
INT24U
Unsigned integer, 0 to 16 777 215
IEC 61850-7-2
INT32
-2 147 483 648 to 2 147 483 647
IEC 61850-7-3,
IEC 61850-7-2
INT32U
Unsigned integer, 0 to 4 294 967 295
IEC 61850-7-3,
IEC 61850-7-2
INT8
-128 to 127
IEC 61850-7-3,
IEC 61850-7-2
INT8U
Unsigned integer, 0 to 255
IEC 61850-7-3,
IEC 61850-7-2
IntgPd
Integrity Period
IEC 61850-7-1,
IEC 61850-7-2
IP
Internet Protocol
IEC 61850-3
ISC
Integer Step Controlled position information
IEC 61850-7-3
ISCSO
Integer Status Controllable Status Output
IEC 61850-7-4
ISI
Integer Status Information
IEC 61850-7-3
ISO
International Organization for Standardization
IEC 61850-1
IT
Current x Time product
IEC 61850-7-4
ITCI
Logical node - Remote control interface or telecontrol interface IEC 61850-5
ITMI
Logical node - Remote monitoring interface or telemonitoring
interface
IEC 61850-5
km
Kilometer
IEC 61850-7-4
L
Lower
IEC 61850-7-4
LAN
Local Area Network
IEC 61850-5
LC
LOG CONTROL Class *
IEC 61850-7-2
LC
Logical Connection (p. 217) *
IEC 61850-5
LCB
Log Control Block
IEC 61850-7-2
LD
Logical Device
IEC 61850-7-1
Ld
Lead
IEC 61850-7-4
LD0
Logical Device Zero (0)
IEC 61850-7-2
LDC
Line Drop Compensation
IEC 61850-7-4
LDCR
Line Drop Compensation Resistance
IEC 61850-7-4
LDCX
Line Drop Compensation Reactance (X)
IEC 61850-7-4
LDCZ
Line Drop Compensation Impedance (Z)
IEC 61850-7-4
LDInst
Instantiated Logical Device
IEC 61850-6
ldNs
logical device Name space
IEC 61850-7-3
LED
Light Emitting Diode
IEC 61850-7-4
Len
Length
IEC 61850-7-4
Lev
Level
IEC 61850-7-4
Lg
Lag
IEC 61850-7-4
