NOTE: The Windows software installer installs the HP Smart Device Agent Base service. The file size is less than
100 kb. Its only function is to check for printers connected via USB hourly. No data is collected. If a USB printer is
found, it then tries to locate a JetAdvantage Management Connector (JAMc) instance on the network. If a JAMc is
found, the HP Smart Device Agent Base is securely upgraded to a full Smart Device Agent from JAMc, which will
then allow printed pages to be accounted for in a Managed Print Services (MPS) account. The driver-only web
packs downloaded from www.hp.com for the printer and installed through the Add Printer wizard do not install
this service.
To uninstall the service, open the Control Panel, select Programs or Programs and Features, and then select Add/
Remove Programs or Uninstall a Program to remove the service. The file name is HPSmartDeviceAgentBase.
Mobile printing solutions
HP offers multiple mobile printing solutions to enable easy printing to an HP printer from a laptop, tablet,
smartphone, or other mobile device.
To see the full list and to determine the best choice, go to www.hp.com/go/MobilePrinting .
NOTE: Update the printer firmware to ensure all mobile printing capabilities are supported.
● Wi-Fi Direct (wireless models only, with HP Jetdirect 3100w BLE/NFC/Wireless accessory installed)
● HP ePrint via email (Requires HP Web Services to be enabled and the printer to be registered with
HP Connected)
● HP Smart app
● Google Cloud Print
● AirPrint
● Android Printing
● HP Roam
Printer dimensions
Make sure your printer environment is large enough to accommodate the printer.
Table 1-10 Dimensions for the base printer—M776dn
Dimension Printer fully closed Printer fully opened
Height 710 mm (28 in) 1025 mm (40.4 in)
Depth 663 mm (26.1 in) 1103 mm (43.4 in)
Width 585 mm (23 in) 1051 mm (41.4 in)
Weight 70.9 kg (156.3) 70.9 kg (156.3)
Table 1-11 Dimensions for the M776z printer
Dimension Printer and accessories fully closed Printer and accessories fully opened
Height 1034 mm (40.7 in) 1475 mm (58.1 in)
Depth 712 mm (28 in) 1115 mm (43.9 in)
