Load and print labels, Manually feed labels, Label orientation – HP Color LaserJet Enterprise Flow M776z All-In-One Laser Printer User Manual
Page 71: Manually feed labels label orientation
Load and print labels
To print on sheets of labels, use Tray 1 or the 550-sheet trays.
●
●
Manually feed labels
Use the manual feed mode to print sheets of labels.
1.
From the software program, select the Print option.
2.
Select the printer from the list of printers, and then click the Properties or Preferences button to open the
print driver.
NOTE:
The name of the button varies for different software programs.
NOTE:
To access these features from a Windows 8.1 Start screen app, select Devices, select Print, and
then select the printer.
NOTE:
To access these features from Windows 10, select Print, and then select the printer.
3.
Click the Paper/Quality tab.
4.
In the Paper size drop-down list, select the correct size for the sheets of labels.
5.
In the Paper type drop-down list, select Labels.
6.
In the Paper source drop-down list, select Manual feed.
NOTE:
When using manual feed, the printer prints from the lowest-numbered tray that is configured for
the correct size of paper, so it is not necessary to specify a particular tray. For example, if Tray 2 is
configured for labels, the printer will print from Tray 2. If Tray 3 is installed and configured for labels, but
Tray 2 is not configured for labels, the printer will print from Tray 3.
7.
Click the OK button to close the Document Properties dialog box.
8.
In the Print dialog box, click the Print button to print the job.
Label orientation
Labels need to be loaded in a specific manner in order to print correctly.
ENWW
Load and print labels
57
