* The LLC life test conditions:
● Print coverage: 5% evenly distributed across the page
● Environment: 17° to 25°C (62.6° to 77°F); 30%-70% relative humidity (RH)
● Media size: Letter/A4
● Media weight: 75 g/m2 (20 lb) plain media
● Job size: 4 pages or more on average
● Long-edge feed (Letter/A4)
Factors that can reduce life from the conditions above:
● Media narrower than Letter/A4 widths (thermal slowdowns equal more rotations)
● Paper heavier than 75 g/m2 (20 lb) (heavier media creates higher stress on printer components)
● Print jobs smaller than 4 pages (smaller jobs mean more thermal cycling and more rotations)
Customer self-repair parts
Customer Self-Repair (CSR) parts are available for many HP LaserJet printers to reduce repair time.
NOTE: More information about the CSR program and benefits can be found at www.hp.com/go/csr-support and
www.hp.com/go/csr-faq .
Genuine HP replacement parts can be ordered at www.hp.com/buy/parts or by contacting an HP-authorized
service or support provider. When ordering, one of the following will be needed: part number, serial number
(found on back of printer), product number, or printer name.
● Parts listed as Mandatory self-replacement are to be installed by customers, unless you are willing to pay
HP service personnel to perform the repair. For these parts, on-site or return-to-depot support is not
provided under the HP printer warranty.
● Parts listed as Optional self-replacement can be installed by HP service personnel at your request for no
additional charge during the printer warranty period.
Table 3-5 Customer self-repair parts
Item Description Self-replacement options Part number
550-sheet paper tray Replacement 550-sheet paper tray Mandatory T3V27A
Toner collection unit Replacement toner collection unit Mandatory 3WT90A
Fuser Replacement fuser Mandatory 4YL16A (110V)
4YL17A (220V)
Image transfer kit Replacement intermediate transfer belt,
secondary transfer roller, and paper tray
rollers
Mandatory 3WT89A
Foreign interface harness Replacement foreign interface harness Mandatory B5L31A
Internal USB ports Replacement internal USB ports Mandatory B5L28A
Secure Hard Disk Drive Replacement hard disk drive Mandatory B5L29A
62 Chapter 3 Supplies, accessories, and parts ENWW
