TNT 12000
Users Manual
2-42
TNT 12000
DoseMate W/mAs
OR
TNT 12000
mAs Shunt
mAs Cable
Ground Marker
BNC Female to
Banana Plug Adapter
Test Lead (Red)
Test Lead (Black)
mAs Input
ION Chamber
Input
mAs Input
TNT 12000WD
W/mAs
1/4-20 Threaded Insert
fct23.eps
Figure 2-19. mAs Test Leads Connection
