Create Graphic User Interface (GUI) Screen
Select the Map GUI Set-up button.
Navigation Toolbar
Create new map(s) using Create Map toolbar icon:
• Enter Map Name (text entry).
Import picture into map using Import Map toolbar icon.
• Select file name to be imported.
Area Map screen
Draw lines on map to identify broadcast areas
Area Map screen
Define properties of each area (mouse right click)
• Enter description (text entry).
• Select destination (pull-down list).
• Select color to be displayed on map. (color pallet).
Locate Icon pop-up location for each area.
• Move ball icon (mouse left click and hold).
Select text pop-up window location.
• Select quadrant (mouse right click on ball).
Area Map screen
