• Tally indicator — Indicates current operational status by colors, as follows:
• Red : Recording
• Green : Playing
• Orange : Cued. Media is loaded and ready to play.
• Gray : Idle. No media loaded.
• Toolbar — Provides buttons for access to panel functions.
• Asset type icon — Appears when an asset is loaded and indicates the type of asset.
• Single channel — Operates one channel.
• Scrub bar slider — Finds scenes quickly within a clip or playlist.
• Show/Hide transport controls — Shows or hides transport controls on a channel or a gang.
You can open multiple Channel Panels and use them simultaneously to suit your workflow needs.
Channel Panel buttons
These buttons located on the Channel Panel toolbar let you perform various functions:
Salvo : Loads, creates, or removes a salvo.
Save : Saves the current settings. The settings are saved to the Channel Panel configuration.
Trash : Removes an item, such as a channel or production element, from the panel when you
drag and drop the item on the icon.
View Mode : Controls the display and size of the items in a list or panel.
These transport control buttons let you control channels:
New Clip : Creates a new clip and allows you to name the clip before recording.
Cue Start : Cues to the beginning of the asset.
Record : Starts recording. Toggles with Stop button.
Stop : Stops recording. Toggles with Record button.
Play : Plays the clip. Toggles with the Pause button.
Pause : Pauses the play operation. Toggles with Play button.
Eject : Ejects the current asset.
These buttons located on the channels and gangs in the Channel Panel extend the functionality of
controls:
Add Marker : Logs an item for the current position.
Go to Previous Marker : Goes to previous keyword/marker.
Go to Next Marker : Goes to next keyword/marker.
Loop Playback : Loops the current asset between mark in to mark out.
Show/Hide Control Tray : Shows or hides the control tray.
116 GV STRATUS User Manual 2014 02 21
Working with K2 channels
