• Markers and keywords that are between mark in and mark out
The following is not inherited:
• Custom metadata
• Approval status
• Locked status
Related Topics
About GV STRATUS markers, Dyno markers, and the K2 database
Trimming a clip in Inspector
When you trim an asset, you change the length of the viewable asset, restricting it to the material
between the Trim In and Trim Out points. The material outside the trim marks is not deleted. It
remains on disk but is not viewable. To use the Trim Asset operation, you must be logged on with
a user account to which the Trim Rights role is assigned. If the role is not assigned, the Trim Asset
operation is not available.
1. Load the asset into the Inspector.
2. Navigate to the desired starting point using the scrub bar, and click the Mark In button. (
I )
3. Navigate to the desired end-point using the scrub bar, and click the Mark Out button. ( O )
Where timecode is displayed you can also right-click the timecode type label and select Clear
Marks to clear all current in/out marks.
4. Click on the Actions drop-down arrow, and select Trim Asset .
Adding keywords
You can add keywords to assets that are loaded in GV STRATUS Viewers. In the Sequence Viewer
tool and in the Channel Panel tool you cannot add keywords, but you can add markers.
1. Load the selected asset into the Viewer.
2. If the logging controls are not shown, click the Show/Hide Control Tray button to show the
controls, then the drop-down arrow at the right of the control tray and Add/Remove buttons if
necessary.
3. Click the Add Keyword button. ( ` )
The New Keyword dialog box opens.
4. Enter the name of the keyword.
You can also add the description, tags, rating, and angle if needed.
5. Click OK .
The keyword is added to the asset. A symbol indicates its location. If you select a symbol the
thumbnail associated with that point is loaded into the Viewer, and the slider is moved to that
position.
2014 02 21 GV STRATUS User Manual 171
Editing
