If you hover the mouse pointer over a symbol, its thumbnail and properties appear.
Related Topics
Adding markers on page 172
Adding markers to a playlist on page 174
Adding markers
You can add markers to assets that are loaded in GV STRATUS Viewers. In the Sequence Viewer
tool and the Channel Panel tool you can add markers but not keywords.
1. Load an asset into the Viewer or Channel Panel.
If a Channel Panel, record a clip or load an already recorded clip.
2. If the logging controls are not shown, do the following:
• If a Viewer, individual Channel Panel, or Channel Panel gang, click the Show/Hide Control
Tray button to show the controls, then the drop-down arrow at the right of the control tray
and Add/Remove buttons if necessary.
• If a channel in a Channel Panel gang, double-click the channel to show the controls.
3. Click the Add Marker button. ( ` )
The New Marker dialog box opens.
4. Enter the name of the marker.
You can also add the description, tags, rating, and angle if needed.
5. Click OK .
The marker is added to the asset. A symbol indicates its location. If you select a symbol the thumbnail
associated with that point is loaded into the Viewer, and the slider is moved to that position.
