Using the Audio Overlay
The audio overlay is available on the Source Viewer, the Sequence Viewer, and the Inspector. The
number of meter bars displayed depends on the number of audio channels associated with the asset.
1. On the Source Viewer, the Sequence Viewer, or the Inspector player, hover your mouse pointer
on the top left of the asset.
The audio overlay of the asset displays.
2. You can manage audio for the asset by clicking the appropriate button:
• To mute specific audio channels, click the Mute button.
• To isolate the selected audio channel while muting others, click the Solo button.
3. Click the Pin Audio button to pin the audio overlay and fix it in place.
4. Click the Collapse Audio button to show or hide meter bars display of audio channels.
The Source Viewer
The Source Viewer allows you to preview assets, both assets already recorded and assets currently
being recorded. The Source Viewer appears in the application as a standalone panel when you select
it in the
Window | Panels menu or from the Navigator. However, the Source Viewer appears in a
composite panel when you launch Advanced Logging or Storyboard Editor.
