Creating a sequence
1. Open the Storyboard Editor tool and then do one of the following:
• On the Storyboard toolbar, click the New Sequence button. A New Sequence dialog box
opens. Enter the name of your sequence, select a K2 bin, and then click OK .
• In the Navigator panel, right-click a K2 bin and select New | Sequence . A New Sequence
dialog box opens. Enter the name of your sequence and then click OK .
• Right-click in the empty space of a K2 bin Asset List and select New | Sequence . A New
Sequence dialog box opens. Enter the name of your sequence and then click OK .
2. Select an asset in a K2 bin Asset List and drag it to the Source Viewer panel.
The asset name displays in the title bar.
3. Choose one of the following actions:
• To preview the asset, click the Play button or use the appropriate transport controls.
• To create a mark-in point, click the the Mark In button.
• To create a mark-out point, click the Mark Out button.
4. Drag the asset to the Storyboard. ( C )
The asset is now in the timeline of the Storyboard and referred to as an event.
5. Repeat above steps to add additional events.
6. In the panel, use the toolbar buttons to modify events.
7. Click the Save button to save the sequence. If you have not yet named the sequence, a Save
As dialog box opens. Name the sequence and select the K2 bin in which to save the sequence.
To preview the sequence, use the transport controls in the Sequence Viewer.
Editing an event
1. Double-click an event on the timeline of the Storyboard.
The event opens in the Source Viewer.
2. To edit, mark in and mark out the event.
The event duration automatically updates in the Storyboard.
There is no Undo feature for these operations.
Splitting an event
1. Navigate to the desired location in the event.
2. Select the Split button.
The event is divided into two events with identical names.
There is no Undo feature for these operations.
2014 02 21 GV STRATUS User Manual 177
Editing
