Other Data Rate Frame Rate Sampling Format
50 Mbps 59.94, 50 4:2:2 AVC-Ultra G50
1280x720p
Avid DNxHD formats
The following formats are for Avid DNxHD content. These are supported for record input (encode)
and play output (decode). A Summit 3G Codec board with a K2-XDP2-DNX-2CH license is required.
Other Bits Data Rate Frame Rate Format
Avid DNxHD 220x 10 220 Mbps 29.97 1920x1080i
Avid DNxHD 220 8 220 Mbps 29.97
Avid DNxHD 145 8 145 Mbps 29.97
Avid DNxHD 185x 10 184 Mbps 25
Avid DNxHD 185 8 184 Mbps 25
Avid DNxHD 120 8 121 Mbps 25
Avid DNxHD 220x 10 220 Mbps 59.94 1280x720p
Avid DNxHD 220 8 220 Mbps 59.94
Avid DNxHD 145 8 145 Mbps 59.94
Avid DNxHD 175x 10 175 Mbps 50
Avid DNxHD 175 8 175 Mbps 50
Avid DNxHD 115 8 116 Mbps 50
Playout of multiple formats
The K2 Summit/Solo system automatically handles material of various types and formats as specified
in the following sections:
Playout on K2 Summit/Solo
For a given frame rate, you can play SD clips of any format back-to-back on the same timeline.
Both 16:9 and 4:3 SD aspect ratio formats can be played on the same timeline. Refer to video codec
description earlier in this section for a list of the supported formats.
On channels with the XDP (HD) license, for similar frame rates (25/50 fps or 29.97/59.95 fps), SD
material transferred or recorded into the K2 Summit/Solo system along with its audio is up-converted
when played on a HD output channel. Likewise, HD material is down-converted along with its audio
when played on an SD output channel. HD and SD clips can be played back-to-back on the same
timeline, and aspect ratio conversion is user configurable.
The K2 Summit/Solo system supports mixed clips with uncompressed and compressed (PCM, AC3,
and Dolby) audio on the same timeline.
