QuickTime video and key import specification
This specification applies to importing a QuickTime file with two video tracks for video and key
playout. This is a licensed feature.
The imported file must be QuickTime 32 with alpha RLE 32-bit raster encoding, as produced by
the Apple Animation Codec.
Supported video formats for import are as follows:
Frame Rate Scan Format
29.97 Interlaced 720 x 480 SD video
29.97 Interlaced 720 x 512
25 Interlaced 720 x 576
25 Progressive 720 x 608
29.97, 25 Interlaced 1920 x 1080 HD video
59.94, 50 Progressive 1280 x 720
Supported audio formats for import are as follows:
Format
Mono or stereo 48 kHz Audio tracks
(if present)
16 bit, 24 bit
PCM
Interchange mechanisms are supported as follows:
Support Mechanism
Yes Import File based
No Export
No Import FTP stream
No Export
When K2 software imports a file that meets the above requirements, it creates a K2 clip with two
video tracks, in formats as follows:
Data Rate Frame Rate Format
50 CBR 29.97 720 x 512 D10/IMX SD video
50 CBR 25 720 x 608 D10/IMX
100 Mbps 29.97, 25 1920 x 1080 AVC-Intra
100 HD video
100 Mbps 29.97, 25 1280 x 720 AVC-Intra
100
