Modifying a salvo
1. Identify the salvo to modify by hovering your mouse pointer over a salvo button.
A tooltip displays the salvo name.
2. Click the Salvo button to load the salvo, if it is not already loaded.
3. Eject or load clips to modify the salvo.
4. Right-click the salvo button and select Create Salvo .
A dialog box opens and prompts you for a salvo name.
5. Click OK .
Do not change the salvo name, so your modifications overwrite the salvo.
The modified salvo is saved as part of the Channel Panel configuration.
You must save the Channel Panel configuration to save the modified salvo.
Configure router settings in Channel Panel
Before doing this task, make sure that in GV STRATUS Control Panel your router connection
settings are configured.
You can set the router source and destination for a channel in a Channel Panel, and save the setting
with the Channel Panel configuration.
1. Launch a Channel Panel.
2. Identify the channel for which you are making router settings.
You can make router settings for a channel in a gang or for a channel not in a gang.
3. Right-click the channel and select Router Settings .
The Router Settings dialog box opens.
4. Configure router settings as follows:
• Source : The feed coming into the router, such as from a camera.
• Destination : The port coming out of the router, connecting to the K2 system channel.
5. Click OK to save settings and close.
6. Repeat steps to configure router settings on other channels in the Channel Panel as desired.
7. Click the the Save button in the toolbar.
8. When prompted to confirm, click Replace .
This updates the current Channel Panel configuration with your changes.
