Importing keywords configuration
You can import K2 Dyno keywords configuration from an XML file into Button Panels of your
Logging Tool.
1. Drag a Logging Tool into the Inspector.
The Logging Tool configuration loads in the Inspector and you can see the list of Button Panels
under the
Views tab.
2. Right-click on the list of Button Panels and select Import .
The Select xml file dialog displays.
3. Browse to the location of the XML file, and select it.
4. Do one of the following:
• To merge keywords configuration into a single Button Panel, let the Merge into single panel
checkbox be selected as default.
• To import keywords configuration into separate Button Panels, deselect the Merge into single
panel checkbox.
5. Click OK .
A progress bar displays the importing process.
Logging buttons and Button Panels are created in the Logging Tool according to the imported XML
file.
