399
P
eripherals and Optional A
c
c
essories
11
Viewfi nder Tilt Adapters
Using the EVF-TL1
Swivel the viewfi nder into the desired position.
Swiveling the Viewfi nder Up or Down
Loosen the tilt lock knob and swivel the
viewfi nder up or down from 0° to 90°.
With the viewfi nder in the desired posi-
tion (
A
), tighten the tilt lock knob (
B
)
to lock the viewfi nder in place.
Swiveling the Viewfi nder Left or Right
Release the horizontal swivel lock as
shown and swivel the viewfi nder left or
right ±45°.
With the viewfi nder in the desired po-
sition (
A
), return the horizontal swivel
lock to the latched position (
B
) to lock
the viewfi nder in place.
