Overview
Slave Controller – IP Core for Altera FPGAs III-5
1.6 Tested FPGA/Designflow combinations
The EtherCAT IP Core has been synthesized successfully with different Quartus II versions and FPGA
families. Table 3 lists combinations of FPGA devices and design tools versions which have been
synthesized or even tested in real hardware. This list does not claim to be complete, it just illustrates
that the EtherCAT IP Core is designed to comply with a broad spectrum of FPGAs.
Table 3: Tested FPGA/Designflow combinations
IP
Core Family Device Designflow Test Used Example
Designs
3.0.10
Cyclone III EP3C40 Quartus II 13.1.4 Hardware DBC3C40 Digital
I/O
Cyclone III LS EP3CLS200 Quartus II 13.1.4 Synthesis
Cyclone IV E EP4CE55 Quartus II 14.1 Hardware DBC4CE55 Nios
Cyclone IV E EP4CE115 Quartus II 14.1 Hardware DE2-115 Nios
Cyclone V 5CEBA2 Quartus II 14.1 Synthesis
Cyclone V SoC 5CSEMA5 Quartus II 14.1 Synthesis
Stratix III EP3SE50 Quartus II 13.1.4 Synthesis
Stratix IV E EP4SE230 Quartus II 14.1 Synthesis
Stratix IV GT EP4S40G Quartus II 14.1 Synthesis
Stratix IV GX EP4SGX70 Quartus II 14.1 Synthesis
Stratix V 5SGSMD4 Quartus II 14.1 Synthesis
Arria II GX EP2AGX45 Quartus II 14.1 Synthesis
Arria V 5AGXMB3 Quartus II 14.1 Synthesis
Arria V GZ 5AGZME5 Quartus II 14.1 Synthesis
Intel Atom
E6x5C
EP2AGXE
6XXFPGA Quartus II 13.1.4 Synthesis
MAX10 10M40DA Quartus II 14.1 Synthesis
NOTE: Synthesis test means analysis, synthesis, fitter, and assembler. Hardware test means the design was
operational using real hardware.
NOTE: Turn on Analysis & Synthesis option: Auto RAM Replacement, otherwise the RAM inside the IP Core will
be implemented with individual registers.
Refer to the Hardware Data Sheet Section III Addendum available at the Beckhoff homepage
(
http://www.beckhoff.com ) for latest updates regarding device support, design flow compatibility, and
known issues.
