Example Designs
III-56 Slave Controller – IP Core for Altera FPGAs
6.4 Altera Cyclone IV DE2-115 with NIOS and RGMII
6.4.1 Configuration and resource consumption
Table 16: Resource consumption NIOS example design DE2-115 RGMII
Configuration Resources EP4CE115
Physical layer 2x RGMII,
MIIM, Link state and PHY
configuration through MI Les 19,182 17 %
Internal Function 3x FMMU
4x SyncManager
1 KB RAM Registers 9,106 8 %
Distributed clocks 32 bit,
2x Sync, 2x Latch M9K 264 61 %
Feature details AL Status Code register,
Extended Watchdog,
AL Event Mask register,
Watchdog counter, EPU
and PDI Error counter,
Lost Link Counter,
RUN_LED,
LED Test PLLs 1 25 %
PDI Avalon
32 bit Multiplier
elements 0 0 %
6.4.2 Functionality
Configure ETHERNET0 and ETHERNET1 for RGMII mode by setting jumpers JP1 and JP2 to 1-2.
The DE2-115 example design with RGMII ports is equal to the DE2-115 example design with MII,
except for the PHY connection. Refer to DE2-115 example design with MII for more details.
6.4.3 Downloadable configuration file
An already synthesized time limited OpenCore Plus configuration file
DE2_115_EtherCAT_NIOS_RGMII_time_limited.sof
based on this digital I/O example design can be found in the
<IPInst_dir>\example_designs\DE2_115_NIOS_RGMII\
folder. After expiration of about 1 hour the design quits its operation unless the JTAG connection to
Quartus remains active. This file must only be used for evaluation purposes, any distribution is not
allowed.
