YASKAWA TM.iQp.10 Technical Manual Supplement 53
DC Braking
b2-01 0189
DC Injection Braking Start
Frequency
DCInj Start Freq Sets the frequency at which DC injection braking starts when ramp to stop
(b1-03 = 0) is selected. If b2-01 < E1-09, DC injection braking starts at E1-
09.
0.0 ~
10.0 Hz
0.5 Hz Programming
b2-02 018A
DC Injection Braking
Current
DCInj Current
Selects the DC injection braking current as a percentage of the drive rated
current.
0 ~ 100 % 50 % Programming
b2-03 018B
DC Injection Braking
Time at Start
DCInj Time @ Start
Sets the time length of DC injection braking at start in units of 1 second.
0.00 to
10.00 sec
0.00 sec Programming
b2-04 018C
DC Injection Braking
Time at Stop
DCInj Time @ Stop
When b1-03 = 2 actual DC Injection time is calculated as follows:
b2-04 x 10 x Output Frequency/E1-04. When b1-03 = 0, this parameter
determines the amount of time DC Injection is applied to the motor at the
end of the decel ramp. This should be set to a minimum of 0.50 seconds
when using HSB. This will activate DC injection during the final portion
of HSB and help ensure that the motor stops completely.
0.00 ~
10.00 sec
0.5 sec Programming
b2-09 01E1
Motor Pre-Heat Current
Preheat Current
Motor Pre-heat current in % of drive rated current. This is used to keep the
motor warm to prevent condensation and is used in conjunction with a
digital input (data = 60).
0 ~ 100 % 0 % Programming
Speed Search
b3-01 0191
Speed Search Selection
SpdSrch at Start
Enables/disables and selects the speed search function at start.
0: SpdsrchF Disable - Speed search at start is disabled (estimated speed
method is used at other times)
1: SpdsrchF Enable - Speed search is enabled (estimated speed method)
2: SpdsrchI Disable - Speed search at start is disabled (current detection
method is used at other times)
3: SpdscrhI Enable - Speed search is enabled (current detection method)
Estimated Speed Method: Actual motor speed and direction is estimated,
then the motor is ramped from that speed to the commanded speed.
Current Detection Method: Current level is monitored while output
frequency is ramped down.
0 ~ 3 2 Programming
b3-02 0192
Speed Search Deactivation
Current
SpdSrch Current
Used only when b3-01 = 3. Sets the speed search operation current as a
percentage of drive rated current.
0 ~ 200 % 120 % Programming
b3-03 0193
Speed Search Deceleration
Time
SpdSrch Dec Time
Used only when b3-01 = 3. Sets the deceleration time during speed search.
0.1 ~
10.0 sec
2.0 sec Programming
b3-05 0195
Speed Search Delay Time
Search Delay Delays the speed search operation after a momentary power loss to allow
time for an external output contactor to re-energize. 0.0 ~
20.0 sec
0.2 sec Programming
b3-14 019E
Bidirectional Speed Search
Selection
Bidir Search Sel
0: Disabled
1: Enabled
0 ~ 1 1 Programming
Delay Timers
b4-01 01A3
Timer Function ON-Delay
Time
Delay-ON Timer Used in conjunction with a multi-function digital input and a multi-
function digital output. This sets the amount of time between when the
digital input is closed, and the digital output is energized.
0.0 ~
3000.0 sec
0.0 sec Programming
b4-02 01A4
Timer Function OFF-
Delay Time
Delay-OFF Timer Used in conjunction with a multi-function digital input and a multi-
function digital output. This sets the amount of time the output stays
energized after the digital input is opened.
0.0 ~
3000.0 sec
0.0 sec Programming
PI Control
b5-01 01A5
PI Mode Setting
PI Mode
This parameter enable /disables the closed loop (PI) controller.
0: Disabled
1: Enabled (commanded speed becomes PI setpoint)
2: Enabled - 2 Zone (dual zone PI enabled)
<0034>
0 ~ 2 1 Programming
b5-02

01A6
Proportional Gain Setting
P Gain
Sets the proportional gain of the PI controller.
0.00 ~
25.00
2.00 Programming
b5-03

01A7
Integral Time Setting
PI I Time Sets the integral time for the PI controller. A setting of zero disables
integral control. 0.0 ~
360.0 sec
3.0 sec Programming
b5-04

01A8
Integral Limit Setting
PI I Limit
Sets the maximum output possible from the integrator. Set as a % of fmax.
0.0 ~
100.0 %
100.0 % Programming
b5-06

01AA
PI Output Limit
PI Limit Sets the maximum output possible from the entire PI controller. Set as a %
of fmax. 0.00 ~
100.00 %
100.00 % Programming
 Denotes that parameter can be changed when the drive is running.
Parameter
No.
Addr.
Hex
Parameter Name
Digital Operator
Display
Description
Setting
Range
Factory
Setting
Menu
Location
