Chapter 7 Digital Channel RIGOL
MSO1000Z/DS1000Z User’s Guide 7-1
Chapter 7 Digital Channel
The mixed signal digital oscilloscopes of MSO1000Z/DS1000Z series provide 4 analog
channels as well as 16 digital channels. For the digital channels, the oscilloscope
compares the voltages acquired in each sample with the preset logic threshold. If the
voltage of the sample point is greater than the logic threshold, it will be stored as
logic 1; otherwise, it will be stored as logic 0. The oscilloscope displays the logic 1
and logic 0 in figure form for users to easily detect and analyze the errors in circuit
design (hardware design and software design). This chapter introduces how to use
the digital channels of the mixed signal digital oscilloscopes.
Before using the digital channels, connect the oscilloscope and the device under test
using RPL1116 logic probe provided in the accessories. For the using method of the
logic probe, refer to the RPL1116 Logic Probe User’s Guide .
Note: The digital channel input terminal does not support hot plug. Please do not
insert or pull out the logic probe when the instrument is powered on.
The contents of this chapter:
 To Select the Digital Channel
 To Turn on/off the Digital Channel
 Group Set
 To Set the Waveform Display Size
 Reorder Setting
 Auto View
 To Set the Threshold
 To Set the Label
 Probe Calibration
 Digital Channel Delay Calibration
