RIGOL MSO/DS1000Z Series - Manual (Page 221)

Chapter 14 Store and Recall RIGOL
MSO1000Z/DS1000Z User’s Guide 14-7
To Create a New File or Folder
This operation is only valid in external storage. Before using external disk, make sure
that a USB storage device is connected correctly.
First, press Storage  DiskManage and use
to select and open the external
disk ("Disk D"). Then, select the desired directory under which you need to create a
new file or folder. The default is the root directory of the USB storage device. Finally,
select the desired file type and press New File or press New Folder directly to turn
on the interface as shown in the figure below.
Figure 14-2 To Create a New File or Folder
This oscilloscope supports Chinese/English input method. The file name or folder
name can contain letters, numbers, underscores, spaces and Chinese characters and
the length of the characters is limited to 31 bytes. The following part introduces how
to input a file name or folder name using Chinese/English input method.
Operation Tip
During the name input, use the menu softkeys to select different operation areas,
then turn to select the desired content and press down to input the
content selected.
