TA Triumph-Adler DCC 2520 - Manual (Page 124)

Other Features of this Fax
5-22
Entering Documents into an F-Code Confidential Box
Perform the following procedure when you want to enter documents into your F-Code Confidential
Box for transmission under the F-Code Based Bulletin Board function. Using this procedure, you
can add new documents to those currently in your F-Code Confidential Box, and you can also
delete all of the documents currently in that box and replace them with new documents.
NOTE: If you want to delete the data for documents stored in an F-Code Confidential Box, simply
print out those documents. (Refer to Printing Out Documents from an F-Code Confidential Box on
page 5-20.)
If you want to cancel the procedure part way through, press the Reset key. The touch panel will
return to the initial mode settings.
1 Set the documents you want to transmit.
2 Press the [Application] key. The
Application screen will appear.
3 Press the [Sub. conf. box Input] ([Scan
orig. to box]) key.
4 Press the key which displays the
subaddress for the F-Code Confidential
Box you want to enter documents into.
If you want simply to add documents to
those already in memory, or you want to
delete all of the documents currently in
memory and replace them with new
documents, go to the next step.
If you are entering documents for this
Confidential Transmission for the first time, go directly to step 7.
5 If you want to add documents, press the [Add] key. If you want to replace the documents, press the
[Overwrite] key.
Place the original & assign destination.
Dest
Ready for fax transmission.
Basic Application
Abbrev.
TX Address
Register
setting book
Print Report
Memory
OCT-11
RX Polling
TX Polling
Basic Application Register
box input
Sub.conf.
TX status
Reserved
on LCD
TX result
on LCD
RX result
data box
Print encr
box output
Sub.conf.
Memory
OCT-11
Print Report
Option screen
Select item.
Subaddress confi. box
1111 .
(Original is at box indicated reverse)
Back
Scan original to confidential box.
1234 .
Memory
OCT-11
1/7 .
