117
Editing Parameters
MASTER EQUALIZER
SHORTCUT: Press and Hold the [MASTER EQ] button.
Th is Page allows you to adjust the overall tonal quality of the instrument.
EQ ON/OFF
Th is allows you to turn the Master Equalizer “ON” or “OFF.”
NOTE: This Parameter is linked to the [MASTER EQ] button on the Control Panel.
FREQUENCY
Setting Range: 20 ~ 308 [Hz] (BASS)
125 ~ 4k [Hz] (MID)
3k ~ 8k [Hz] (TREB)
Th ese allow you to adjust the center or “turnover” frequency to be attenuated for BASS,
MID and TREBLE respectively.
GAIN
Setting Range: -9 ~ ±0 ~ +9 [dB]
Th ese allow you to adjust the Boost/Cut of BASS, MID and TREBLE respectively.
NOTE: At “0” the frequency response is “fl at.”
Q
Setting Range: 0 ~ 63
Th is allows you to adjust the “Q” (Quality Factor) or Resonance of the MID Frequency
Band. A higher value results in a greater emphasis of the cutoff frequency, causing a
“ringing” eff ect.
NOTE: Use this Parameter along with the GAIN Parameter for the maximum eff ect.
NOTE: Setting both the GAIN and the Q at maximum will result in the maximum coloration
of the sound.
ATTACK - BASS GAIN
DECAY - MID FREQUENCY
SUSTAIN - MID GAIN
RELEASE - TREBLE GAIN
NOTE: The MASTER EQUALIZER Parameters are
System Parameters. You must Record
these Parameters if you want their
settings to be remembered the next
time the instrument is turned “ON.” See
page 143 for instructions on how to do
this.
Frequency
Gain
0dB
+9dB
-9dB
BASS
Gain
TREBLE
Gain
TREBLE
Freq.
BASS
Freq.
20 - 308 3k - 8k
Minimum
Maximum
Quality Factor
MIDDLE
Gain
MIDDLE
Freq.
125 - 4k
In this page, you can use the AMPLITUDE ENVELOPE
sliders in the MONO SYNTH section to adjust the MASTER
EQUALIZER Parameters (see the illustration on the left).
