*#1 SK PRO/SK PRO-73 Owner’s Manual
16
BASIC CONNECTIONS
Connect audio cables and accessories as shown below.
Th
e SK PRO/SK PRO-73 is not self-contained - an external amplifi er/speaker system is required in order to hear the sound.
However, if you connect a set of stereo headphones to the PHONES jack, you can hear the sound through the headphones
even if an external amplifi er is not connected.
NOTE: Be sure that both the instrument and amplifi er are “OFF” before connecting amplifi ers or headphones.
CAUTION
This instrument draws a slight amount of power even if the
[POWER] switch is “OFF.” Therefore, if the instrument will not
be used for a long period of time, disconnect the AC plug
from the outlet.
Do not place this instrument in direct sun light, near heat
sources, or in a hot location.
NOTE: The Expression Pedal, Foot Switch and Damper Pedal Parameters must be set
properly. This is explained in more detail starting on page 132.
to AC Outlet
Powered Speakers
(optional)
Foot Switch
FS-9H (optional)
Expression Pedal
EXP-50J (optional)
Damper Pedal
VFP1 (optional)
