ORGAN SECTION IN DETAIL
KEYBOARDS AND PARTS
Th e classic Hammond Organ has two manuals or keyboards and a pedal keyboard
(or pedal clavier). Commonly, the two keyboards will be registered diff erently - for
example, the Upper Keyboard will have a registration appropriate for Melody while
the Lower Keyboard will have an Accompaniment registration to provide harmonic
backing for the Melody. In addition, the Pedals will have a setting appropriate for bass
notes.
Th
e ORGAN Section of the SK PRO can function as a classic Hammond Organ by
dividing or “Splitting” the keyboard into two Parts. When SPLIT is active, “UPPER”
is the portion of the keyboard to the right of the SPLIT Point and “LOWER” is to the
left of the SPLIT Point.
In addition, the PEDAL Part can be played either from a connected MIDI pedalboard,
or from the keyboard by using the PEDAL TO LOWER feature when SPLIT is active.
[ 3 PART ORGAN] button
Th is allows you to select whether the ORGAN Section will function as a classic
Hammond Organ with two manuals and pedals or as a single-manual organ.
Upper
Lower
OFF
Green: LOWER keyboard
Sounds UPPER part.
Upper
Lower
ON
Green: LOWER keyboard
Sounds LOWER part.
ON ...............The ORGAN Section will function as a classic two-manuals-and-pedals Hammond
Organ.
OFF .............The ORGAN Section can either sound on the entire keyboard, or be dynamically
assigned to UPPER, LOWER or PEDAL.
[ DRAWBAR SELECT] buttons
Allow you to use the Drawbars to control the sounds for each ORGAN Part. If the
LED of one of these buttons is lit, the Drawbars will control the sounds represented
by that button.
