Hammond SK Pro-73 73-Key Portable Keyboard/Organ - Manual (Page 118)

*#1 SK PRO/SK PRO-73 Owner’s Manual
118
RECORDING A COMBINATION OR PATCH
After you have made changes to a Combination or Patch, you will most likely want
to Record them for future use. To do this, follow the instructions on this page.
PRESS THE RED [RECORD] BUTTON
After you have made your changes to a Combination or Patch,
press the red [RECORD] button. Th
e RECORD Page will
display.
SELECT THE ITEM TO RECORD
CONTENT
Use the [VALUE] knob to select the Bundle, Manual,
Combination or Patch you wish to Record. Th
e choices are
shown below.
Bundle
This allows you to Record COMBINATION, ORGAN and MONO
SYNTH Parameters in one group so that Patches can be
created in fewer steps. See page 26 for more information
about Bundles.
Manual
This allows you to Record COMBINATION, ORGAN and MONO
SYNTH Parameters into the MANUAL except the values of
knobs or sliders.
Combination Patch
Organ Patch
Piano Patch
Ensemble Patch
Synth Patch
System
Th e “E” (Edited) icon appears if the content is edited from
recalled setting.
TO
Use the DIRECTION [

] button to move the cursor to “TO.”
Use the [VALUE] knob to select the User Number to Record.
CATEGORY
If the Patch to be Recorded is a PIANO or ENSEMBLE
Patch, use the DIRECTION [
 ] button to move the cursor
to “CATEGORY” and use the [VALUE] knob to select the
Category.
RECORD
After you have done Steps 1 through 3 above, use the
DIRECTION [
 ] button to move the cursor to the [RECORD]
icon and press the [ENTER] button. Th e Naming screen will
display.
NAME THE ITEM
Enter the Name.
[Aa1] ................. Changes the character type.
[1] - [10] .......... Selects the highlighted character.
[Insert] ............ Inserts a space at the cursor.
[Delete] ........... Deletes a letter at the cursor.
[VALUE] ........... Changes the letter at the cursor.
After you are fi nished Naming, press the [ENTER] button. Th e
message shown below will display for approximately 1 second:
NOTE: Do not turn the power “OFF” while the above message is
displaying.
NOTE: If you DO NOT wish to Record, press the [MENU/EXIT] button
instead of the [ENTER] button.
RETURN TO THE PLAY MODE
Press the [PLAY] button to return to the PLAY mode.
