183
Appendix
SYSTEM EXCLUSIVE MESSAGE
MEMORY DUMP
1. Each Packet (139 Bytes)
F0
System Exclusive
55
SUZUKI ID
dd
Device ID (refer to page 159)
10
Model ID MSB
24
Model ID LSB
11
Command: Data Packet
[TYPE]
Data Type
07H, 08H = Temp. Dump
0AH = System Dump
[PNH]
Packet Number MSB
[PNL]
Packet Number LSB
[DATA]
64 Bytes Data
128 Bytes nibblized ASCII
ex: 7EH = 37H, 45H
[CHD]
Check Digit
Lower 7 bits of XOR [DATA]
F7
End Of Exclusive
2. Acknowledge
F0
System Exclusive
55
SUZUKI ID
dd
Device ID
10
Model ID MSB
24
Model ID LSB
14
Command: Acknowledge
[TYPE]
Data Type
[AK]
Result
00H = OK
05H = Check Digit Error
06H = Receive Protected
[PNH]
Packet Number MSB
[PNL]
Packet Number LSB
F7
End Of Exclusive
3. # of Packets
Temp. Dump:
46
System Dump:
11
DUMP REQUEST (Rx. Only)
F0
System Exclusive
55
SUZUKI ID
dd
Device ID
10
Model ID MSB
24
Model ID LSB
12
Command: Dump Request
[TYPE]
Data Type
07H = Temp. Dump
0AH = System Dump
F7
End Of Exclusive
NRPN SWITCH
F0
Suzuki Exclusive
55
SUZUKI ID
dd
Device ID
10
Model ID MSB
24
Model ID LSB
02
Command: NRPN Sw.
[DATA]
00H = Off , 7FH = On
F7
End Of Exclusive
When this device receives this message, Tx & Rx NRPN is switched in the Control
channel.
DATA SET (RX. ONLY)
F0
System Exclusive
55
SUZUKI ID
dd
Device ID
10
Model ID MSB
24
Model ID LSB
13
Command: Data Set
aa
Address MSB
bb
Address
cc
Address LSB
[DATA]
Data (Flexible bytes)
F7
End Of Exclusive
IDENTITY REQUEST (RX. ONLY)
F0
System Exclusive
7E
Universal non real-time
dd
Device ID
06
Sub ID #1
01
Sub ID #2
F7
End Of Exclusive
IDENTITY REPLY (TX. ONLY)
F0
System Exclusive
7E
Universal non real-time
dd
Device ID
06
Sub ID #1
02
Sub ID #2
55
SUZUKI ID
00 10
Device Family code
00 24
Device Family number
00 00
00 00
F7
End Of Exclusive
When Identity Request is received, Identity Reply will be transmitted.
DRAWBAR DATA LIST
Control Number
Part
16´
5 1⁄3´
8´
4´
2 2⁄3´
2´
1 3⁄5´
1 1⁄3´
1´
Upper
0CH(12)
0DH(13) 0EH(14)
0FH(15)
10H(16)
11H(17)
12H(18)
13H(19)
14H(20)
Lower
15H(21)
16H(22)
17H(23)
18H(24)
19H(25)
1AH(26)
1BH(27)
1CH(28)
1DH(29)
Pedal
21H(33)
-
23H(35)
-
-
-
-
-
-
Level
0
1
2
3
4
5
6
7
8
Value
00 - 0FH
(0 - 15)
10 - 1FH
(16 - 31)
20 - 2FH
(32 - 47)
30 - 3FH
(48 - 63)
40 - 4FH
(64 - 79)
50 - 5FH
(80 - 95)
60 - 6FH
(96 - 111)
70 - 7EH
(112-126)
7FH
(127)
ex: Set Lower 8´ to level 7 via MIDI. Bx 17 70 (x=Upper Channel)
