tree is the shortest path from the IPv6 multicast source to the receivers, it is also called shortest path tree
(SPT).
The operating mechanism of IPv6 PIM-DM is summarized as follows:
• Neighbor discovery
• SPT establishment
• Graft
• Assert
Neighbor discovery
In an IPv6 PIM domain, a PIM router discovers IPv6 PIM neighbors, maintains IPv6 PIM neighboring
relationships with other routers, and builds and maintains SPTs by periodically multicasting IPv6 PIM
hello messages to all other IPv6 PIM routers on the local subnet.
NOTE:
Every IPv6 PIM–enabled interface on a router sends hello messages periodically, and thus learns the IPv6
PIM neighboring information pertinent to the interface.
SPT establishment
The process of constructing an SPT is the flood-and-prune process.
1. In an IPv6 PIM-DM domain, an IPv6 multicast source first floods IPv6 multicast packets when it
sends IPv6 multicast data to IPv6 multicast group G. The packet undergoes an RPF check. If the
packet passes the RPF check, the router creates an (S, G) entry and forwards the packet to all
downstream nodes in the network. In the flooding process, an (S, G) entry is created on all the
routers in the IPv6 PIM-DM domain.
2. Nodes without downstream receivers are pruned. A router that has no downstream receivers
sends a prune message to the upstream node to notify the upstream node to delete the
corresponding interface from the outgoing interface list in the (S, G) entry and stop forwarding
subsequent packets addressed to that IPv6 multicast group down to this node.
NOTE:
•
An (S, G) entry contains the multicast source address S, IPv6 multicast group address G, outgoing
interface list, and incoming interface.
• For a given IPv6 multicast stream, the interface that receives the IPv6 multicast stream is called
"upstream," and the interfaces that forward the IPv6 multicast stream are called "downstream."
A leaf router first initiates a prune process. As shown in Figure 100 , a router without any receiver
attached to it (the router connected with Host A, for example) sends a prune message, and this prune
process continues until only necessary branches remain in the IPv6 PIM-DM domain. These branches
constitute the SPT.
