404
Task Command Remarks
Display information about
join/prune messages to send.
display pim ipv6 join-prune mode { sm [ flags
flag-value ] | ssm } [ interface interface-type
interface-number | neighbor
ipv6-neighbor-address ] * [ verbose ] [ | { begin |
exclude | include } regular-expression ]
Available in any view.
Display IPv6 PIM neighboring
information.
display pim ipv6 neighbor [ interface interface-type
interface-number | ipv6-neighbor-address |
verbose ] * [ | { begin | exclude | include }
regular-expression ]
Available in any view.
Display information about IPv6
PIM routing table.
display pim ipv6 routing-table
[ ipv6-group-address [ prefix-length ] |
ipv6-source-address [ prefix-length ] |
incoming-interface [ interface-type
interface-number | register ] | outgoing-interface
{ include | exclude | match } { interface-type
interface-number | register } | mode mode-type |
flags flag-value | fsm ] * [ | { begin | exclude |
include } regular-expression ]
Available in any view.
Display RP information.
display pim ipv6 rp-info [ ipv6-group-address ] [ |
{ begin | exclude | include } regular-expression ] Available in any view.
Reset statistics for IPv6 PIM
control messages. reset pim ipv6 control-message counters [ interface
interface-type interface-number ] Available in user
view.
IPv6 PIM configuration examples
IMPORTANT:
By default, Ethernet interfaces, VLAN interfaces, and aggregate interfaces are in the state of DOWN. To
configure such an interface, use the undo shutdown command to bring it up first.
IPv6 PIM-DM configuration example
Network requirements
Receivers receive VOD information through multicast. The receiver groups of different organizations form
stub networks, and one or more receiver hosts exist in each stub network. The entire IPv6 PIM domain is
operating in the dense mode.
Host A and Host C are multicast receivers in two stub networks N1 and N2.
MLDv1 runs between Switch A and N1 and between Switch B/Switch C and N2.
